CWM664

The CWM664 is an in-wall speaker distinguished by its 25mm (1in) soft dome tweeter. It brings smoother and more detailed high frequency performance to a package that also includes a woven glass fibre 150mm (6in) bass/midrange driver and three-position high frequency switch to fine tune the sound. Installation is catered for by a simple and effective QuickDog™ fixing system. The CWM664 is an elegantly engineered and cost effective route to high quality in-wall sound.

Description : 2-way in-wall system
Drive units : 1x ø25mm (1in) Nautilus™ tube loaded aluminium dome tweeter
                    1x ø150mm (6in) black glassfibre cone bass/midrange
Frequency Range (-6dB) : 45Hz – 35kHz
Maximum Amp Power : 25 – 130w
Sensitivity SPL (2.83V, 1m) : 87.5dB
Impedance Nominal (min) : 8Ω (4.5Ω)
Frame height : 315mm (12.4in)
Frame width : 221mm (8.7in)
Cut-out height : 279mm (11in)
Cut-out width : 183mm (7.2in)
Depth behind surface : 95mm (3.7in)
Protrusion : 4mm (0.2in)
Pre-mount Kit : PMK W6
Back Box : BB W6
