Cambridge Audio Edge A Integrated Amplifier
SKU: Cambridge Audio Edge A.Color : Dark titanium
Get it with 0% Credit Card Instalment Plan Up to 36 months
1) Maybank Credit Card up to 12 months ( Lazada )
2) Maybank Credit Card up to 18 months ( Shopee )
3) PBB Credit Card up to 12 months ( Shopee )
4) OCBC Credit Card up to 36 months ( SLAV )
EDGE A
INTEGRATED AMPLIFIER
合并式解码扩音机
Our most detailed integrated amplifier.
Edge A is made to celebrate musicality. Riffs, phrases, percussive rolls – take in every detail of your music thanks to its dynamic setup. Effortlessly powerful, but with incredible depth, the overall sound is breath-taking – like you’re sat in the recording booth with the musicians.
我们最出色的合并式解码扩音机
Edge A 的出现是为了庆祝音乐。借助其动态设置,吸收音乐的每一个细节。毫不费力地强大,但具有令人难以置信的深度,整体声音令人叹为观止 - 就像你坐在音乐家的录音棚里一样。
Breath-taking musicality.
Edge A is designed to bring musical detail to life. It delivers a finely balanced sound with a depth and clarity that come through with every note. We developed the system by ear, testing every component and only choosing those that blew us away. The end result is a ground-breaking arrangement that produces a much cleaner signal path and lets your music breathe. Edge A perfectly delivers our classic British sound – nothing added, nothing taken away.
呼吸的音乐
Edge A 旨在将音乐细节带入生活。它提供了精细均衡的声音,每一个音符都会带来深度和清晰度。我们通过耳朵开发系统,测试每个组件并仅挑选那些能感动我们的组件。最终带来的是一个开创性的结果,产生一个更干净的信号路径,让你的音乐呼吸。 Edge A 完美呈现了我们经典的英国声音 - 没有任何添加,亦没有任何取走。
More musical detail.
We pioneered the use of toroidal transformers in amplifiers, which led to improved performance. In Edge we take this one step further, using opposing symmetry twin toroidal transformers. This cancels out electromagnetic interference whilst offering outstanding power and maintaining consistent tonality, no matter how loud it’s played.
更多的音乐细节
Edge A 采用一个相反对称的双环形变压器。通过将两个主变压器背靠背堆叠,我们大大减少了杂散磁场,并且几乎消除了有害的嗡鸣声。因此,无论您播放 Edge A 多大声,音色都不会有任何变化 - 您的耳朵将会听到扎实的低音、明亮的高音和干净开放的中音。
Effortless power without distortion.
Using standard Class A amplifier technology wasn’t going to be efficient enough for Edge A. Instead we added a bias voltage to a traditional Class AB design, reducing distortion to inaudible levels. This unique configuration also produces less heat and makes the whole system much more effective.
轻松推动而不失真
使用标准的 A 类放大技术对于 Edge A 来说效率会不够高。相反,们在传统的 AB 类设计中增加了一个偏压,从而将分频点转移到人耳听不到失真的位置。这种独特的配置有助产生较少的热量,并使整个系统更加有效率。
Hi-res bluetooth.
Pair any Bluetooth device to your Edge A to easily stream your music. With aptX HD support, you can play your audio at up to 24-bit/48kHz quality for an incredibly rich listening experience.
高清蓝牙
将任何蓝牙设备与您的 Edge A 配对,就能轻松流畅播放音乐。由于支援 aptX HD 的关系,您可以播放高达 24bit/48kHz 的音乐档案,享受令人难以置信的丰富聆听体验。
Sonic balance.
Edge A was designed with a unique PCB. Our engineers replaced conventional capacitors with a DC coupled topology and also added a solid state volume control. The end result is a clean signal path that’s perfectly balanced at any volume.
声道平衡
Edge A 采用独特设计的 PCB 。我们的工程师用直流耦合拓扑替代传统电容器,并增加多重数码模拟转换器 (MDAC) 。最终得到的结果便是一个干净的信号路径,在任何音量下都能达到完美的声道平衡。
Perfect partners.
Edge systems are designed to work in perfect synchronisation. Match the performance of Edge A with loudspeakers to make the foundations of a hi-fi system unlike anything else.
最佳的拍档
Edge 系统是通过共享的工程设计理念互相连接的。将 Edge NQ 与我们最出色的功率放大器 Edge W 匹配,创建一套与其他任何设备不同,带有高质声音和完美外观的高保真音响系统。
Need Extended Warranty? Click Here:
https://www.stylelaser.com.my/product/style-extended-warranty/
CONTINUOUS POWER OUTPUT
100W RMS into 8 Ohms; 200W RMS into 4 Ohms
THD (UNWEIGHTED)
<0.002% 1kHz at rated power (8 Ohms); <0.02% 20Hz – 20kHz at rated power (8 Ohms)
FREQUENCY RESPONSE
<3Hz – >80kHz +/-1dB
S/N RATIO (REF FULL POWER)
>103 dB
CROSSTALK @ 1KHZ
< -100dB
INPUT SENSITIVITY
Input A1-A2 (unbalanced) 380mV RMS
INPUT IMPEDANCES
Input A3 (balanced) 47k Ohm; Input A1-A2 (unbalanced) 47k Ohm
INPUTS
Balanced, Coax S/PDIF, TOSLINK, USB Audio, Unbalanced, Bluetooth, Audio Return Channel (ARC)
OUTPUTS
Speakers, Preamplifier, Headphones (impedance of between 12 and 600 ohms are recommended)
USB AUDIO INPUT
USB Audio Class 2.0 supporting up to 32-bit 384kHz PCM, or up to DSD256
BLUETOOTH
4.1 (Smart/BLE enabled) A2DP/AVRCP supporting formats up to aptX HD
TOSLINK INPUT
16/24 bits, 32-96kHz
COAX S/PDIF INPUT
16/24 bits, 32-192kHz
MAX POWER CONSUMPTION
1000W
STANDBY POWER CONSUMPTION
<0.5W
DIMENSIONS
150 x 460 x 405mm (5.9 x 18.1 x 15.9")
WEIGHT
24.4kg (53.7lbs)
