DALI RUBICON 5

With a large cabinet volume and a hybrid tweeter module containing both a soft dome and ribbon tweeter, the floor standing RUBICON 5 extend and widen the high frequencies for a crisp detail. The bass is deep and perfectly timed for a more demanding presence. All this add up to a potent loudspeaker despite its still compact size.

SMC MAGNET SYSTEM

With a pole piece constructed entirely from SMC, surrounded by a slitted copper cap, and enclosed within a large ferrite magnet, the effect of the SMC is focused and maximised, and reduces distortion as never heard before.

HYBRID TWEETER MODULE

The hybrid tweeter module is a DALI trademark and for the RUBICON series, it is build in Denmark. The hybrid tweeter module, combines the dome tweeter with the ribbon tweeter for an amazing rendering of the high frequencies.

CABINET CONSTRUCTION

Dividing the mid-range and basse drivers into separated chambers enables us to individually tune every driver to its specific frequency range to maximise the woofer output.

WOOD FIBRE CONES

Using a wood fibre cone gives the in-house build woofer a light, rigid and randomly uneven membrane. Making it easy to move ensures even piston like movements and reduces the possibility of surface resonance greatly.

PRODUCT DETAILS

Producing superior sound at a size that’s just right for the averagely proportioned living space, the RUBICON 5 is the first of the floorstanding loudspeakers within the RUBICON family. Combining that bigger internal capacity with our unique ribbon/soft dome hybrid tweeter module, the RUBICON 5 extends and widens higher frequencies to deliver a flawless soundstage of impeccably crisp detail and perfectly precise bass response to bring your music to life.

RUBICON 5 is a floor standing loudspeaker. It expands the sonic performance of the RUBICON 2 by adding a hybrid tweeter and a larger cabinet offering more of everything. Extending and widening the high frequencies for improved detail, and adding more well timed deep bass for a more demanding presence.

The RUBICON 5 is perfect for stereo listening or as the front speakers in a medium sized surround setup combined with a pair of RUBICON 2 or RUBICON LCR as the back speakers and a RUBICON VOKAL as the center speaker.

DALI RUBICON 5 SPECS
Product series    RUBICON
Frequency Range (+/-3 dB) [Hz]    45 - 34.000
Sensitivity (2,83 V/1 m) [dB]    86.0
Nominal Impedance [ohms]    4
Maximum SPL [dB]    107
Recommended Amplifier Power [W]    60 - 150
Crossover Frequency [Hz]    2,900 / 14,000
Crossover Principle    2½ + ½-way
Hybrid tweeter module, Super high freq. driver, Quantity    1 x 17 x 45 mm
Hybrid tweeter module, Super high freq. driver, Diaphragm type    Ribbon
Hybrid tweeter module, High frequency driver, Quantity    1 x 29 mm
Hybrid tweeter module, High frequency driver Diaphragm type    Soft Textile Dome
Low frequency driver, Quantity    1 x 6½"
Low frequency driver, Diaphragm type    Wood Fibre Cone
Enclosure type    Bass Reflex
Bass Reflex Tuning Frequency [Hz]    39.0
Connection Input    Bi-Wiring
Magnetic Shielding    No
Recommended Placement    Floor
Recommended Distance From Wall [cm]    20 - 150
Dimensions With Base (HxWxD) [mm]    890 x 195 x 339
Accessories Included    Manual
Micro Fibre Cloth
Rubber Bumpers
Spikes M8
Weight [kg]    15.7
