AVR-X1800H

Enjoy incredible 8K video and 3D audio from the AVR-X1800H. It easily fills small to medium-size rooms with brilliant audio from a 7.2 or 5.2.2 set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, you can wirelessly stream music and share with every HEOS-enabled speaker around your home.

Overview

Enjoy incredible 8K video and 3D audio from the AVR-X1800H. It easily fills small to medium-size rooms with brilliant audio from a 7.2 or 5.2.2 set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, you can wirelessly stream music and share with every HEOS-enabled speaker around your home.

Key Features

• Denon® quality sound: Fill small to medium rooms with dynamic Denon sound.
• Immersive 3D audio: Feel fully enveloped in your music or movie sound.
• Audyssey room correction: Optimize the listening experience in your room.
• Geared for 8K: Enjoy amazing video quality from the latest 8K technology.
• Music streaming throughout your home: With HEOS® Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.

START WITH QUALITY THAT YOU CAN HEAR

Superior versatility. Crafted audio brilliance.

IMMERSIVE 3D AUDIO

Feel fully enveloped in your music or movie sound.

GEARED FOR 8K

Enjoy amazing video quality from the latest 8K technology.

MUSIC STREAMING THROUGHOUT YOUR HOME

With HEOS® Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.

DUAL SUBWOOFER OUTPUTS

Connect up to two subwoofers for more balanced bass performance throughout the room.

Dolby Atmos

Feel every dimension in Dolby Atmos. Upgrade your home theatre with a 5.1.2-speaker setup to unleash a fully immersive 3D audio experience from Dolby Atmos content. Dolby Surround upmixer engages all speakers to create 3D audio sensations from legacy content. Dolby Atmos Height Virtualization Technology creates the sensation of overhead sound even without height speakers installed. You can also enjoy Dolby Atmos music tracks available from Apple Music, Amazon HD, and TIDAL and a compatible streaming device.

DTS:X

DTS:X immersive audio content places sound where it would naturally occur in space, creating lifelike, multidimensional audio. DTS Neural:X upmixer offers improved immersion and heightened realism for legacy content. DTS Virtual:X provides immersive audio without height channels, creating virtual height effects in a 7.1, 5.1, or 2.1- speaker setup.

HDMI Connectivity with ARC/eARC

Supports the latest technology on all HDMI inputs and output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV receiver simple, with just a single HDMI connection. eARC provides HD and 3D audio transmission such as Dolby TrueHD, DTS HD Master Audio, and Dolby Atmos while ARC is limited to conventional 5.1ch audio formats or PCM.

8K/HDCP 2.3

Enjoy pristine 8K picture quality on your 8K TV or projector. Supports both 8K pass-through and 8K upscaling of 4K content. Supports HDCP 2.3, the latest copy protection standard, for peace of mind when streaming copy-protected content.

Brilliant colour from HDR 10+

Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10+ pass-through. HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10+ use dynamic metadata to optimize shadows and highlights as screens change.

Dolby Vison

Dolby Vision is a stunning HDR imaging technology that brings extraordinary colour, contrast, and brightness to the screen. Enjoy Dolby Vision content from a compatible source device and TV.

Next generation gaming

Supports Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM) for smooth, lagfree gaming experience when connected with the compatible gaming devices.

HEOS Built-in

With HEOS® Built-in technology, stream your favourite music wirelessly through Spotify, Tidal, Amazon Music HD, AirPlay 2, Bluetooth and more. Enjoy the world of internet radio supported by TuneIn. Add Denon Home speakers to share music to additional rooms in your house and control it all with the HEOS app. Play the same song in every room or select a different song for each connected room.

Airplay 2 and Apple Siri Voice Control

Use AirPlay 2 to stream Apple music wirelessly to the AV receiver, or group with other AirPlay compatible speakers to fill your home with music.

Works with Amazon Alexa

Control your AV receiver handsfree with Amazon Alexa and your voice. Adjust the volume, skip to the next track, switch inputs for your different media players, and more—“Just Ask.” Download the free HEOS Home Entertainment Skill to enable Amazon Alexa voice commands. Requires Alexa app and Amazon Echo, Dot, or equivalent. Availability of features varies by region.

High-resolution audio support

Enjoy superb audio fidelity with your favourite highresolution audio tracks. The supported formats are ALAC, FLAC and WAV at up to 192kHz/24 bit. It is also compatible with 2.8/5.6- MHz DSD files. Play HD audio tracks from a USB drive or other connected drives over a network or from Amazon Music HD with subscription. Conventional MP3 and WMA files are also supported.

Bluetooth audio transmitter

Pair your favourite Bluetooth headphones with your AV receiver to continue listening to your favourite music, movies, or TV programs at night. You can also play audio from both speakers and Bluetooth headphones simultaneously. If you have a family member or a friend who is hearing impaired, we recommend this setup. You can connect one pair of headphones at a time.

Multi-source, multi-room

By connecting a pair of speakers in a second room to the AV receiver, it’s possible to enjoy 5.1-channel surround sound in the main room and a separate source or music stream in the second room, such as den or patio. You can also play the same audio in both so that everyone in your home can enjoy and cheer your favourite team on Sunday evening or listen to the same song in both rooms. The AV receiver supports 2-source, 2- zone audio.

Denon Setup Assistant

Award-winning guide Denon Setup Assistant supplies simple, clear instructions to get started. Just connect your AV receiver to your TV and follow the instructions on the TV screen to connect your speakers, perform speaker measurements, and connect source devices. For additional convenience, the AV receiver renames HDMI inputs automatically when connected or you can rename manually at your convenience.

Audyssey suite of room correction technology

Denon AV receivers use the Audyssey suite of EQ software for simple, accurate setup and calibration. With the supplied Audyssey measuring microphone, Audyssey measures all the speakers in your home theatre, and tunes the AV receiver to provide the smoothest, most optimal overall listening experience for your room. This AV receiver supports Audyssey MultEQ XT room-correction technology. The other supported Audyssey features are Dynamic EQ and Dynamic Volume.

Audyssey MultEQ Editor app

You can go even further with the Audyssey MultEQ Editor app, going “under the hood” to view and adjust settings for detailed tuning—allowing you to customize the sound more precisely to the specific problems in your room and tailor the sound to your personal preferences. With this comprehensive app, you can harness the power of Audyssey MultEQ to take total control of the way your home cinema sounds. The app is available for purchase in iOS and Google Play stores.

Denon AVR Remote app

This iOS or Android control app allows you to control your AV receiver, such as changing inputs, sound modes, volume, store and retrieve Quick Selects, show AV receiver (AVR) status, input and output signal information, change optional settings, and so on. Once HEOS music is selected, the AVR remote app automatically switches to the HEOS app for seamless operation between two apps.

Technical Information
Number of Power Amps 7
Power Output
80 watts per channel
(8 ohm, 20 Hz–20 Khz,
 0.08% 2ch drive)
120 watts per channel
(6 ohm, 1 kHz,
 0.7% 2ch drive)
175 watts per channel
(6 ohm, 1 kHz,
 10% 1ch drive)
Other
Compatible with Remote
App for smart phones Denon AVR Remote
Auto Speaker Setup
by Microphone Audyssey MultEQ XT
Front Display 1-Line FLD
GUI Languages English, Japanese, French

General
System Remote Control RC-1257
Power Consumption 430 W
Power Consumption
(No Sound, ECO on/off) 29W/39W
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Maximum Dimensions (W × D × H)
Antenna: Horizontal (in)
Antenna: Vertical (in)
17.1 × 13.3 × 6.0
17.1 × 13.3 × 8.5
Weight (lbs) 19.0

Ports
Video
HDMI In/Out 6/1
Multi-Room Video Out: Video, HDMI None
Audio
Analog In/Out 2/-
Phono (MM) In Yes
Digital in: Optical/Coaxial 2/1
Multi-Room Out: Analog/Digital 1/-
Multichannel Pre-Out Yes (2.2)
Subwoofer Out 2
Other
Number of speaker terminals 7
