Marantz VS3003

The Marantz VS3003 HDMI Switcher allows up to three 8K devices to be connected to select Marantz 8K AV receivers.

• Slimline Design
• Connects Three Devices
• 8K Ultra HD
• Easy Setup
• Custom Install Friendly

Compact Size and Elegant Look

No bigger than a Blu-ray case in width and depth, the VS3003 can fit just about anywhere. It also features a premium look thanks to a brushed black Aluminum front plate.

Custom-Install Friendly

A wall-mount bracket is included to allow mounting the HDMI Switcher on a wall. It also features wired IR remote repeater connectivity in case the VS3003 and AVR are in a rack system or behind a cabinet blocking IR reception.

Easy Setup

Use HDMI-CEC to power on and switch inputs automatically on both the HDMI Switcher and the AV receiver.

VS3003
Technical Specs
General
Power Supply AC 100–240V, 50/60Hz
Power Consumption 2.3W (Standby 0.2 W, CEC standby 0.5W)
Maximum Dimensions (W x H x D) 5.5 x 1.3 x 3.9in
140 x 34 x 98mm
Carton Dimensions (Packaging) (W x H x D) 11.2 x 2.7 x 10.8in
285 x 69 x 275mm
Weight 0.7 lbs / 0.3kg
Weight (with Packaging) 2 lbs / 0.9kg
Ports
HDMI In 3x 8K / 40Gbps
HDMI Out 1x 8K / 40Gbps
Remote Control Flasher 1
Compatible Marantz 8K AV Receivers / Amplifiers
AV8805A, AV7706, SR8015, SR7015, SR6015, SR5015, SR5015DAB, NR1711
What's in the box
HDMI switcher (VS3003) 1
Quick Start Guide 1
Safety Instructions 1
Cautions on Using Batteries 1
Remote control unit (RC046, with battery (CR2032)) 1
HDMI cable (40 Gpbs, approx. 1.5 m / 4'10") 1
Power supply cable (USB type, Approx. 1.5 m / 4'10") 1
AC adapter 1
AC adapter plugs (5 types) 5
Wall-mount bracket 1
Mounting screws (4 pieces 4
