MA8950

2-Channel Integrated Amplifier

• 200 Watts x 2 channel
• 5-band tone control
• Comes with DA2 Digital Audio Module installed
• 55% increase in Dynamic Headroom for better music peak reproduction

The MA8950 Integrated Amplifier offers 200 Watts per channel and combines McIntosh's amplification expertise and preamplifier technologies into one comprehensive stereo sound system component. It replaces the award-winning MA8900 (Secrets of Home Theater and High Fidelity 2017 Best Stereo Integrated Amplifier) and adds additional performance enhancements to an already outstanding stereo integrated amplifier.

Dynamic headroom has increased from 2.0dB to 3.1dB in the MA8950 as a result of its filter capacity being doubled. This gives the MA8950 even greater ability to reproduce musical peaks with less distortion. The increased filter capacity will also help deliver more amazing bass playback, low end performance, and overall bass control.

"An amplifier that can handle almost any spread of sources, power almost any pair of speakers and work comfortably in almost any room." Received Editor's Choice Award for Best High-End Stereo Amplifier 2022. - AVForums

The MA8950 comes standard with the DA2 Digital Audio Module instead of the DA1 Digital Audio Module that came in the MA8900. The DA2 offers 7 digital inputs: 2 coaxial, 2 optical, 1 USB, 1 MCT, and 1 audio-only HDMI Audio Return Channel (ARC)¹ connection. TVs with a compatible HDMI (ARC) output can be connected to the MA8950 to enjoy your TV’s sound like never before through your home music system. Popular multi-channel audio formats from Dolby^® and DTS^® are supported and will be expertly converted to 2-channel audio for proper playback. The MA8950 remote can control the TV’s power and volume when CEC communication is enabled in both the amplifier and the TV. The DA2 also features increased DSD playback support of up to DSD512 via the USB input.

The DA2 Digital Audio Module features seven digital audio inputs.

The DA2 is powered by an audiophile-grade, Quad Balanced, 8-channel, 32-bit Digital-to-Analog Converter (DAC) that has improvements in both dynamic range and total harmonic distortion compared to the DAC in the DA1. The coax and optical inputs in the DA2 can decode digital music up to 24-bit/192kHz for playback of high-resolution audio. The DA2 has a McIntosh exclusive MCT input that offers a secure DSD connection to any of our MCT series of SACD/CD Transports to deliver the best possible sound quality of the high-definition audio found on your SACDs. And with its modular design, it's possible to someday replace the DA2 with a newer Digital Audio Module.

The MA8950 Integrated Amplifier offers a comprehensive set of analog and digital audio inputs.

With its vast selection of digital audio inputs, analog connectivity has not been overlooked on the MA8950. It comes with 1 balanced and 6 unbalanced stereo inputs plus 1 Moving Coil and 1 Moving Magnet phono inputs for your turntable(s). All inputs can be given custom names for user-friendly system control and configuration. The Moving Coil phono input comes with adjustable loading so you can fine tune the sound of your vinyl records. All unbalanced analog connectors are made from premium gold-plated solid brass for superior signal handling and grounding. All analog and digital inputs can be given custom names for user-friendly system control and configuration. For further flexibility in setting up your stereo system, the MA8950 includes an unbalanced fixed output and an unbalanced variable output that can be used to send the audio signal to a second power amplifier.

"An amplifier that can handle almost any partnering equipment and speaker and deliver outstanding performance and flexibility with all of it. This is how McIntosh makes hifi and the results are sensational... It delivers sparkling performance while offering enormous connectivity and user friendliness." - Sound Online

Other updates include upgraded power supply components for even lower noise emission and added reliability under the most demanding conditions. The MA8950 continues to use powerful control microprocessors for robust and smooth system operation, as well as some of the latest state-of-the-art audio-grade circuit components to produce the best sound possible.

The Autoformers are located to each side of the power transformer.

The MA8950's 200 Watts per channel are delivered by a pair of the famous McIntosh Autoformer^™ and is enough power to properly drive virtually all loudspeakers. The unique design of the Autoformer guarantees your speakers will always receive the full 200 Watts regardless if they have 2, 4 or 8 Ohm impedance.

Other McIntosh features included in the MA8950 are:

• Power Guard^® that continuously monitors input and output signals and can dynamically adjust input levels to ensure maximum output while avoiding harsh sounding distortion and clipping that could damage your speakers
• Our fuse-less short-circuit protection technology Sentry Monitor^™ that disengages the output stage before the current can exceed safe operating levels and then resets automatically when operating conditions return to normal
• McIntosh Monogrammed Heatsinks^™ that are made from high quality materials with excellent thermal conductivity and heat dissipation properties
• Home Theater PassThru that allows for seamless integration into a home theater system
• High Drive headphone amplifier with Headphone Crossfeed Director (HXD^®) which can bring an added dimension to headphone listening
• A discrete, five-band tone control that allows for advanced manual analog adjustment of ±12dB in 2dB increments of your favorite recordings at frequencies of 30Hz, 250Hz, 500Hz, 2kHz, and 10kHz
• Power Control to send power on/off signals to connected McIntosh components for easy system power up and shutdown
• Gold-plated speaker binding posts that prevent corrosion to ensure a quality signal is sent over your speaker cables to your speakers

McIntosh Monogrammed Heatsink.

The MA8950 is one of many McIntosh products to receive Roon Tested designation from Roon Labs. As a Roon Tested partner, McIntosh has provided equipment to Roon for testing with a variety of different operating systems and computers, and shared information about its design and capabilities.

Five-band tone controls.

The entire unit is wrapped in the timeless McIntosh aesthetic with a black glass front panel with LED lighting, blue watt meters, control knobs, illuminated logo, aluminum end caps and a beautiful polished stainless steel chassis. Contact your local dealer to learn more.

1. The HDMI (ARC) input will only play audio from a compatible TV. It will not pass video to or from a TV, or play audio from any non-TV source.

The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
Dolby is a registered trademark of Dolby Laboratories.
DTS, DTS-HD, the Symbol, & DTS or DTS-HD and the Symbol together are registered trademarks of DTS, Inc. © DTS, Inc. All Rights Reserved.

Power Output per Channel: 200 Watts
Number of Channels: 2
Speaker Impedance: 2, 4, or 8 Ohms
Rated Power Band: 20Hz to 20kHz
Total Harmonic Distortion: 0.005%
Dynamic Headroom: 3.1dB
Frequency Response +0,-0.5dB: 20Hz to 20kHz
Frequency Response, +0, -3dB: 10Hz to 100kHz
Sensitivity Phono (Moving Coil): 0.25mV
Sensitivity Phono (Moving Magnet): 2.5mV
Sensitivity High Level (Balanced / Unbalanced): 0.5V/0.25V
Sensitivity (Power Amp input): 1.4V
Signal To Noise Ratio (Moving Coil): 80dB
Signal To Noise Ratio (Moving Magnet): 82dB
Signal To Noise Ratio (High Level): 95dB
Signal To Noise Ratio (Power Amp input): 113dB
Input Impedance (Balanced / Unbalanced): 20K/20K
Damping Factor: >40
Maximum Output (Balanced / Unbalanced): 8V Unbalanced
Balanced Input: 1
Unbalanced Input: 6
Phono Input Moving Coil: 1 (adjustable loading)
Phono Input Moving Magnet: 1 (fixed loading)
Upgradeable Digital Audio Module: Yes: DA2
Digital Coaxial Input: 2
Digital Optical Input: 2
Digital MCT (DIN) Input: 1
Digital USB Input: 1
HDMI (ARC) Input: 1
Balanced Variable Output: 0
Unbalanced Fixed Output: 1
Unbalanced Variable Output: 2
Headphone Output: 1/4" High Drive with Headphone Crossfeed Director (HXD®)
Subwoofer Output: 0
AM/FM Tuner option: No
Home Theater PassThru: Yes
Unbalanced Analog Connector Type: Standard
Speaker Binding Post Type: Standard
Service Port: 1
Digital-to-Analog Converter (DAC) Type: 8-channel, 32-bit/384kHz PCM/DSD, Quad Balanced
Digital Coaxial Input Sample Rate: 24-bit/44.1kHz to192kHz
Digital Optical Input Sample Rate: 24-bit/44.1kHz to192kHz
Digital MCT (DIN) Input Sample Rate: 16-bit/44.1kHz (CD) / DSD64 (SACD)
Digital USB Input Sample Rate: 32-bit/44.1kHz to 384kHz (PCM) DSD64, DSD128, DSD256, DSD512, DXD352.8kHz, DXD384kHz
Tone Controls: 5-Band
Tone Bypass and Input Assign: Yes
RS232 Control Input: Yes
Power Control Output: 1 Main, 2 Trigger
Rear Panel Data Port: 4
Rear Panel IR Sensor Input: Yes
Input Level Match: Yes
Vacuum Tube or Solid State: Solid State
Output Type: Autoformer™
Output Meters: Yes
Dual Layer Chassis: Yes
Chassis Finish: Polished stainless steel & black painted steel
McIntosh Monogrammed Heatsinks™: Yes
Power Requirement: 120V 50/60Hz, 4.4 amps
Standby Power Requirement: <0.25 Watts
Unit Dimensions (W x H x D): 17-1/2" (44.5cm) x 7-5/8" (19.4cm) x 18-3/4" (47.6cm)
Unit Weight: 75 lbs (34.1 kg)
