BLUE HEAVEN ANALOG INTERCONNECTS

The Blue Heaven LS Analog Interconnect is a fully-shielded design that can be terminated for balanced or single-ended connection. It employs four, heavy-gauge 24 AWG, silver-plated 99.9999% OFC solid core conductors, precision wound in a minimum cross-section configuration that eliminates unnecessary fillers or padding elements. The insulation is high-grade FEP, selected for its superior dielectric performance, while the elegant minimalism extends to the carefully selected low-mass connectors and differential grounding. The result is a high-speed, low-loss interconnect that preserves the sense of musical power and momentum, bringing believable shape and presence to performers, color, life and drama to their performances.

SPECIFICATIONS
Insulation: Fluorinated Ethylene Propylene (FEP)
Construction: Mechanically tuned lay
Conductors: 4 x 24 AWG
Material: Silver-plated 99.99999% solid core OFC
Capacitance: 45.0pF/ft
Inductance: 0.046μH/ft
Overall Shield Coverage: 95%
Velocity of Propagation: 80%
Termination: Gold-plated RCA or XLR
