Sonus Faber Gravis I 8" Active Subwoofer

Sonus Faber Gravis I

The Gravis I and II subwoofers, the collection representing an ideal compromise between size and performance.

BLAST FROM THE PAST

Sonus faber is not new to the arena of subwoofer design and engineering. The first subwoofer project, the Gravis FB100, was launched back in 1986, later followed Cremona M subwoofers. Today, with the new Gravis collection, Sonus faber returns to its roots, incorporating cutting-edge technology while maintaining its identity of natural sound and quality Italian hand-craftsmanship.

THE COMPLETION OF THE PINNACLE

Gravis I and II are the smaller subwoofers of the Gravis Collection.
These speakers have been designed to be easily integrated into every living environment and ideally matched with almost every kind of audio and audio/video system. In addition Gravis I and II are the perfect match for their loudspeaker siblings: the Sonus faber Sonetto Collection.

FEATURES

Gravis I and II deliver incredibly powerful performance from compact subwoofers.


SYSTEM
Sealed box loading, down firing active subwoofer

SPEAKERS
1 x 210 mm (8”) long throw, treated paper cone, wide rubber surround LF unit

AMPLIFICATION
High linearity Class AB
150 W (nominal), 250 W (peak)

FREQUENCY RESPONSE
@ - 6dB, from 30 Hz to Fc (user adjustable)

MAINS INPUT VOLTAGE
Factory selected, 120 Vac – 60 Hz or 230 Vac - 50 Hz

FUSE
T4.0A (110 Vac, 60 Hz); T2.0A (230 Vac, 50 Hz)

CONTROLS
Independent Master and LFE volume controls;
Continuously adjustable Crossover frequency (30 to 120 Hz),
slope 24 dB/oct;
Signal phase inversion switch (0/180°)

AUDIO SIGNAL INPUTS
LFE (Low Frequency Effect) - mono RCA plug; LINE - mono RCA plug; HIGH LEVEL - Neutrik 4-pole Speakon©

POWER CONSUMPTION
0.5 W (Stand-by)
200 W (rated power)

DIMENSIONS (HXWXD)
334 x 286 x 316 mm including feet
13.1 x 11.2 x 12.4 in including feet

WEIGHT
14.5 Kg
32 lb
