Analog Turntable

TN-3B

A new, high-performance standard for belt-drive analog turntables

一種新的高性能皮帶傳動模擬唱盤標準

The TN-3B is a stylish, sleek-looking belt-driven turntable with a built-in MM-type PHONO EQ amplifier and USB digital output.

It employs a new tonearm with knife-edge, pivot-point bearings, collaborated with SAEC, the high-end tonearm manufacturer, for superlative stability and resolution. The belt-drive mechanism, meanwhile, helps mitigate any unwanted cogging effects (ie fine pulsing) from the operation of the motor, to ensure a precise and smooth platter rotation. The TN-3B also employs a VM-type cartridge the AT-VM95E manufactured by audio-technica and a high-precision NJM8080 op-amp in its in-built Phono EQ amplifier, allowing the user to enjoy the sound of their vinyl records with low distortion and in high quality. In addition, a built-in Analog-to-Digital converter and USB port allow users to digitise their vinyl libraries on their PC/Mac.

The TN-3B delivers a natural and well-balanced sound quality and is quick and easy to set up and start enjoying. We believe it sets a new standard that will satisfy the needs of both audiophiles and ardent record collectors.

TN-3B是一款時尚、光滑的皮帶驅動唱盤，內置MM型PHONO EQ擴大器和USB數位輸出。

新款唱臂使用刀緣式樞軸點軸承，與高端唱臂製造商SAEC公司合作，實現最高的穩定性和分辨率。同時，皮帶傳動機構有助於減輕電機運行過程中所產生任何不必要的齒槽效應（即精細脈衝），以確保唱盤旋轉精確、平穩。TN-3B還在其內置的Phono EQ擴大器中採用了高精度NJM8080運算擴大器，使用戶能夠以低失真和高質量享受黑膠唱片的聲音。此外，內置的模擬數位轉換器和USB端口允許用戶在PC/Mac上數位化黑膠唱片庫。

TN-3B提供自然而均衡的音質，可快速輕鬆地進行設置和開始享受。我們相信，這為音響愛好者和熱心的唱片收藏家樹立了一個新的標準。

Knife-edge, pivot-point tone-arm bearings

刀緣，樞軸點音臂軸承

In collaboration with SAEC Corporation, a world-famous, high-end tonearm manufacturer, the TN-3B's tone-arm employs a knife-edge, pivot-point bearing. Unlike the case for tonearms with conventional bearings, any fine vertical movements that take place in this tone-arm actually help in delivering a more dynamic sound with excellent resolution. The S-shaped tone-arm also employs a universal head-shell fitting, allowing users to quickly and easily swap cartridges/head-shells, and supports a wide range of cartridge weights (from 14 - 23g / 0.5 - 0.8 oz.)。

TN-3B的唱臂與世界著名的高端唱臂製造商SAEC公司合作，採用了刀緣式樞軸點軸承。與帶有傳統軸承的唱臂的情況不同，這種唱臂遇到的任何精細垂直運動實際上有助於提供具有出色分辨率的更動態的聲音。 S形唱臂還採用通用的唱頭殼配件，允許用戶快速輕鬆地更換唱頭/唱頭殼，並支持各種唱頭重量（14-23克/0.5-0.8盎司）

Precision anti-skating and stylus-pressure adjustment

精確的防滑和唱針壓力調節

The static-balanced, S-shape tone-arm is equipped with a counterweight for precise stylus-pressure adjustment, as well as an anti-skating mechanism for accurate tracking force adjustment, allowing the cartridge to accurately play any quality vinyl disc.

靜態平衡的S形音臂配有一個平衡物，用於精確的唱針壓力調節，以及一個用於精確跟踪力調節的防滑機構，使唱頭能夠準確地播放任何質量的黑膠唱片。

Pre-installed VM-series cartridge

預裝VM系列唱頭

A VM-type cartridge the AT-VM95E manufactured by audio-technica with an elliptical-shaped stylus tip comes pre-installed on the head-shell for convenience. After you’ve opened the box, set up the platter and mounted the head-shell on the tonearm, you'll be ready to enjoy your records.
* Replacement styli should be available at the retail store where you purchased the unit, or via the TEAC On-line store. (TEAC On-line store is available in selected countries.)
* The VM-series cartridge is a MM (Moving Magnet) type design, and is compatible with all conventional MM-type phono EQ amplifiers.

帶有橢圓形唱針尖端的鐵三角 AT-VM95E唱頭預先安裝在唱頭殼上，方便使用。打開盒子後，設置唱片並將唱頭殼安裝在唱臂上，您就可以享受您的唱片了。
* 更換唱針應在您購買該設備的零售店或通過TEAC在線商店購買。（TEAC在線商店在特定國家/地區購買。）
* VM系列唱頭採用MM（移動磁鐵）型設計，兼容所有傳統的MM型唱盤EQ擴大器。

Built-in MM-type phono EQ amplifier

The TN-3B incorporates an MM-type phono EQ amplifier, allowing you to connect the turntable to a conventional amplifier/hi-fi system that lacks a PHONO input. A low distortion, hi-fi-grade op-amp, the NJM8080, is employed to boost the low-level signals from the phono cartridge up to LINE level.

內置MM型唱機EQ擴大器

TN-3B採用MM型唱頭EQ擴大器，允許您將唱盤連接到缺少PHONO輸入的傳統擴大器/高保真音響系統。低失真，高保真級別的運算擴大器NJM8080用於將唱機唱頭的低電平信號提升至LINE電平。

External belt-drive with aluminum die-cast platter

帶鋁壓鑄盤的外部皮帶傳動

A belt-drive arrangement is employed in order to minimise any motor cogging effects by driving the outer rim of the platter (which has a larger diameter, mass and surface area).

採用皮帶傳動裝置，通過驅動唱片的外緣（其具有較大的直徑，質量和表面積）來最小化任何馬達齒槽效應。

Luxurious, multi-layer lacquer paint finish

All internal components are mounted on a robust and high-density MDF plinth for rigidity and vibration-deadening. Thanks to its sleek and stylish design, the TN-3B looks at home in most domestic environments, creating the perfect setting for listening to vinyl records.

豪華的多層漆面

所有內部部件均安裝在堅固的高密度MDF底座上，以實現剛性和減振。 TN-3B採用時尚的設計，在大多數家庭環境中都能滿足家居需求，為聆聽黑膠唱片創造了完美的環境。

33-⅓ and 45 rpm 2-speed turntable

The TN-3B supports both 33-⅓ and 45 rpm for LP and EP records. Our insistence on quality engineering can even be seen in the construction of the rotary control for start-up/speed selection, formed of machined aluminium.

支持雙速唱盤，轉速為33-⅓和45轉/分

TN-3B支持33-⅓和45轉/分的LP和EP錄音。我們對質量工程的堅持可以從用於啟動/速度選擇的旋轉控制器的構造中體現，該控制器由鋁製機械加工而成。

USB digital output for digital archiving

用於數位存檔的USB數位輸出

A USB port on the back panel delivers CD-quality digital audio to your PC/Mac, allowing you to record/archive your analog library in a high quality, digital audio format. Once you have archived your vinyl to digital, it’s a simple matter to listen to them while out and about, via a smartphone/portable audio player, or in your car (by burning them onto a CD-R or transferring them to a memory card/stick).

And to ensure pristine signal transfer, gold-plated PHONO/LINE output terminals are employed to prevent analog audio signals from losing quality as a result of oxidation.

後面板上的USB端口可為您的PC/Mac提供CD質量的數位音頻，允許您能夠以高質量的數位音頻格式錄製/存檔模擬庫。將黑膠唱片檔案存檔到數位後，通過智能手機/便攜式音頻播放器或車內（通過將它們刻錄到CD-R上或將其轉移到存儲卡上）來聆聽它們變得非常簡單。
為了確保信號傳輸的原始性，採用鍍金PHONO/LINE輸出端子，以防止模擬音頻信號因氧化而損失質量。

Insulating feet with excellent shock absorption

絕緣腳具有良好的減震性能

The insulating feet comprise a machined aluminium shell, topped with a rubber cushion that is fixed to the high-density MDF plinth. Thanks to their excellent shock absorption characteristics, the TN-3B is very resistant to acoustic feedback.

絕緣腳包括一個機械加工的鋁製外殼，頂部帶有橡膠墊，並固定在高密度纖維板基座上。由於其卓越的減震特性，TN-3B對聲音反饋非常有抑制力。

Honeycomb patterned bottom panel

In order to achieve sleek cabinet design without compromising rigidity, the bottom panel is imprinted with a honeycomb pattern that minimises unwanted vibrations.

蜂窩圖案底板

為了在不影響剛性的情況下實現光滑的櫃體設計，底部面板上印有蜂窩狀圖案，可最大限度地減少不必要的振動。

Features at a glance

• Belt-drive mechanism
• 2-speed turntable supporting 33-⅓ and 45 rpm
• Knife-edge, pivot-point tonearm, designed by high-end tonearm manufacturer SAEC
• Aluminum die-cast platter
• Built-in PHONO EQ amplifier compatible with MM-type cartridges
• Hi-fi grade op-amp, NJM8080, used in PHONO EQ stage
• Anti-skating mechanism
• USB digital audio output for digitising records on a PC/Mac
• PHONO/LINE analog output (switchable)
• Gold-plated oxidation-resistant output connectors
• Pre-installed AT-VM95E cartridge supplied by audio-technica
• Rigid, high-density MDF plinth with multi-layered lacquer finish
• Shock-absorbing insulating feet
• GND terminal
• RoHS compliant

功能列表

• 皮帶傳動機構
• 雙速轉盤支持33-⅓和45轉/分
• 由高端唱臂製造商SAEC設計的刀緣，樞軸點音臂
• 鋁壓鑄盤
• 內置PHONO EQ擴大器，兼容MM型唱頭
• PHONO EQ階段使用的Hi-fi級NJM8080運算擴大器
• 防滑機制
• 通過USB數位音頻輸出在PC / Mac上進行數位錄製
• PHONO/LINE 模擬輸出（可切換）
• 鍍金抗氧化輸出連接器
• 預裝鐵三角AT-VM95E唱頭
• 剛性高密度MDF底座，多層漆面
• 減震絕緣腳
• 接地端子

0g to 5.0g
Compatible Cartridge Weight    3.0g to 12.0g
14g to 23g (including Head-shell)
Cartridge section
Type    MM-type
Output Voltage    4.0mV (1kHz, 5cm/sec.)
Needle Pressure    1.8 to 2.2g (2.0g recommended)
Weight    6.1g
Head-shell weight    11g (including screws, nuts, and wires)
Compatible Stylus    AT-VMN95E * Average stylus life: approx. 300 hours.
Analog Outputs
Connector    RCA Pin jack × 1 pair (Gold-plated)
Output Voltage
PHONO    4.0mV (1kHz)
LINE    224mV (–13dBV)
USB Output
Connector    USB B-type (DC 5V 100mA USB Bus power required)
Audio Format    PCM, 8k/11.025k/16k/22.5k/32k/44.1k/48kHz, 16bit
Operating Power    AC 100 to 240V, 50/60Hz
Power Consumption    1.5W
Standby Power    0.5W
Overall Dimensions (W×H×D)    420 × 117 × 356 mm /
16.5" × 4.6" × 14.0" (including protrusions)
Weight    approx. 5.0kg / 11.0 lbs.
