Wharfedale EVO 4.3 Speaker Package

Wharfedale EVO 4.3 Speaker Package

Wharfedale Evo 4.3

Wharfedale Evo 4.3 3 way Speakers are a more compact floorstanding speaker in the Evo range of speakers developed by Wharfedale.

Featuring high performing AMT, soft dome mid-range, SSLP bass reflex system and solid cabinet construction to provide excellently efficient and realistic audio reproduction.

Advanced Technology for less

The highly regarded brand Wharfedale have harnessed technologies and components from the Elysian project models to incorporate into this new range of speakers, which have been designed to be available at a more accessible level.

Air Motion Transformer

Wharfedale Evo 4.3 specifically focuses on implementing Air Motion Transformer tweeter technology for low distortion levels and improved dynamics and resolution.

Sleek Design

The Evo series of speakers are visually stunning and have a tastefully sleek look about them that will remain stylish for years to come. Available in three colour options; walnut, white wood and black, the speakers are designed to fit whatever your taste preference may be.

Durable materials

Not only this, the Evo range incorporate Kevlar fibres which are strong yet lightweight for the woven cone alongside a low-distortion motor system which is fitted with a low-loss rubber surround to produce the most natural-sounding and immersive sound experience.

Evo4.cs

Wharfedale’s new EVO4 has grown out of the extensive research and development that produced the ELYSIAN flagship loudspeakers and borrows much of the technology involved in ELYSIAN.

The primary focus is on the AMT development resulting in a radically different way of reproducing high frequency detail efficiently and accurately. Similar cabinet technology to ELYSIAN provides a stable and solid foundation for the drive units with radiused edges to help integrate the driver output with the room acoustics. In addition the unique SLPP bass reflex system, as developed for ELYSIAN, is now incorporated in EVO4.

沃夫代爾（Wharfedale）的新型EVO4源於廣泛的研發工作，該研究產生了ELYSIAN旗艦揚聲器，並藉鑑了ELYSIAN涉及的許多技術。

主要關注點是AMT的發展，這導致了一種根本不同的有效且準確地再現高頻細節的方式。與ELYSIAN類似的機櫃技術為帶圓角邊緣的驅動器單元提供了穩定而堅實的基礎，有助於將驅動器輸出與室內聲學集成在一起。此外，為ELYSIAN開發的獨特的SLPP低音反射系統現已納入EVO4。

DFS

Designed to be unobtrusive and elegant, yet without any compromise in performance, the DFS models are the ideal solution for multi-functional rooms and lounges with Home Cinema or multi-function systems. Using the same arrangement of drive units as the larger models, the DFS produce the same direct and ambient sound fields, yet are lighter and smaller, with a choice of black cloth (non-removable

DFS stands for ‘Diffuse Field Surround, an ideal for the reproduction of rear surround effects in a bipolar speaker specifically designed and engineered for rear wall mounting. It produces both ambient and direct sound for accurate stereo rear effects. A good rear sound requires both ambient sound and pinpoint stereo imaging. With the Wharfedale DFS speaker, you can recreate a convincing and realistic rear sound field using a single pair of speakers.

The profiled baffle provides exceptional dispersion characteristics for an open and revealing sound while the extruded triangular cross-section is essential for the acoustic nature of the rear sound field.

Tonal matching of a Home Cinema is achieved by using the KEVLAR cones with KEVLAR or carbon-based front speakers, whilst the polypropylene version is more appropriate for other cone materials such as paper/pulp based cones, or indeed, other polypropylene based models.

WCM-65

Wharfedale WCM-65 In-Ceiling Speakers (Pair) introduces the highly acclaimed Wharfedale sound to the Custom Installation market and offers a great performance at an affordable price. WCM-65 features a rotatable tweeter for optimised positioning.

Premium Build

WCM-65 presents Wharfedale’s premium build quality along with a sonically pleasing sound. The trimless exterior design with magnetic micro-perforated grilles ensures a seamless blend between wall or ceiling and speaker. The simplistic and discreet exterior hides the advanced drivers and crossover networks that are housed within.

Quality Materials

The rigid polypropylene bass driver paired with an ultra-durable, high-excursion rubber surround enables stability under high pressure and extensive bass output. Titanium dome tweeters with highly efficient neodymium motor systems complete the wide frequency response with a scintillating high frequency and wide dispersion.

Wharfedale EVO 4.3
3-way floorstanding speaker
wall-mounted installation possible by bass reflex in the base
2 x 130 mm bass driver
1 x 50mm midrange driver
55x80mm AMT tweeter
90 dB efficiency
25 - 150 watts of recommended amplifier power
4 ohms impedance
Frequency range 45Hz-24kHz
Dimensions (HxWxD) 875 x 235 x (295 + 10) mm
Weight per speaker 17.5 kg

Wharfedale EVO 4.CS
General Description    2-way centre speaker
Enclosure Type    bass reflex
Transducer Complement    2-way
Bass Driver    5"(130mm) Black Woven Kevlar® Cone x2
Midrange Driver
Treble Driver    30x60mm AMT
AV Shield    No
Sensitivity (2.83V @ 1M)    89dB
Recommended Amplifier Power    25-100W
Peak SPL    103dB
Nominal Impedance    8Ω
Minimum Impedance    4.4Ω
Frequency Response (+/-3dB)    50Hz ~ 22kHz
Bass Extension (-6dB)    45Hz
Crossover Frequency    2.7kHz
Dimensions (HxWxD)    185 x 585 x (265+10)mm
Net Weight    11.6kg/pcs

DFS
Format    Surround
Bass Driver    2 x 100mm
Tweeter Dome    25mm
Power Handling    15-200W
Impedance    6 Ohms
A/V Shielded    No
Sensitivity(2.83V @ 1m)    86dB
Frequency Response(+3dB)    70-24kHz
HF Limt(-10dB)    44kHz
Crossover Frequency    3.5kHz
System Frequency    80Hz
Dimensions (H x W x D)    280 x 290 x 132 (mm)
Weight 6 kg (each)

WCM-65
Type
- Speaker: Mono
- Power: Passive
- Enclosure: Open design
- Tweeter: Pivoting
- Bass: Fixed flat (165mm)
- Build: Circular, White (Paintable)

Dimensions
- Overall diameter: 225mm
- Cutout diameter: 201mm
- Overall depth: 100mm
- Mounting depth: 97mm

Performance
- Freq range: 65hz - 20khz
- Impedance: 8 - 8 Ohms
- Compatible amp: 20 - 120W RMS
- Sensitivity: 87dB
- Sound pressure: 97dB

Net Weight - 1.23kg
